SRAM RockShox SIDLuxe Select+ 2P User Manual

14
Lever Removal
Lever Removal
Loosen the lever limit screw. Remove the lever.
Remove the flat point screw from the frontside of the eyelet.
Remove the limit screw from the backside of the eyelet.
Remove the detent spring and preloader from the backside of the
eyelet.
Remove the outer cam bushing from the frontside of the eyelet.
Push the lock cam and inner cam bushing out of the eyelet.
1
1.5 mm
2
2 mm 1.5 mm
3
4
