SRAM RockShox SIDLuxe Select+ 2P - RockShox SIDLUXE Remote Removal Procedures; Removing Backside, In, and Out Remotes

15
Remote Removal - Backside, In, and Out
Remote Removal - Backside, In, and Out
Remove the remote cable pulley limit screw.
Remove the remote cable pulley.
Remove the cable hanger bolt. Remove the cable hanger.
For Backside, the cable hanger bolt is also the cam limit screw.
In 1.5 mm Out 1.5 mm
1
Backside 1.5 mm All
In 2 mm Out 2 mm
2
Backside 2.5 mm All
