SRAM RockShox SIDLuxe Select+ 2P User Manual

16
Remote Removal - Backside, In, and Out
Remove the limit screw from the frontside of the eyelet.
In and Out: Remove the limit screw from the backside of the eyelet.
Backside: Remove the cam bushing from the backside of the eyelet.
For Backside, the cable hanger bolt is also the cam limit screw.
Remove the outer cam bushing from the frontside of the eyelet.
Remove the cam assembly from the backside of the eyelet.
In / Out 2 mm Backside 2 mm
3
In / Out 1.5 mm Backside
4
In / Out Backside
5
In / Out Backside
6
