RangerSInstallationandtroubleshooting
9
UsingaConnectedDevice(WeatherStation)
ConnectinganETdeviceon‐sitegivesyouthemostaccurateadjustments
astheETdevicewillmonitortheexactweatherconditionrightwhere
irrigationwilltakeplace.
ET
GND
Rain
GND
Flow
GND
V-Aux
GND
MV
BO1
BO2
NOM
COM COM
--
M204M203M202 M205
Important!Beawareofthepolaritywhenyouconnectdevices
totheRanger4000S:Connectplustoplusandminustominus
oryouwon'tseetheexpectedbehaviorfromtheconnected
devices.
