SRC RANGER 4000 S - Connecting an Alarm

RangerSInstallationandtroubleshooting
35
ConnectinganAlarm
Thegreyterminalslabeled"AUX"areintendedforaregularauxiliaryalarm.
ET GND Rain GND Flow GND V-Aux GND
MV
BO1 BO2
NOM
COM COM
--
M204M203M202 M205
Note:AnalarmisusedinsteadofaFlowSensor.Turnthedial
to SENSOR SETUP andselect N/O eller N/C .
