TestingPrograms
Theeasiestwaytotestwhetheraprogramisrunningcorrectly‐thatis,it
activatesthecorrectstations,mastervalvesandboosterpumprelays‐isto
trytoruntheprogrammanually.
Note:All100stationidentitieswillactivateinturn‐thismeans
thatifyoudon'thaveconnectedstationstoallslotsinthe
connectionboards,youwillexperience"empty"intervals
wherenostationsreacttotheinstructions.
Note:ThetestwillincludetheMasterValvebutnotBooster
Pumps.
Tip:Youcanpausethetestprogramjustasanyregular
program.
Tip:YoushouldenableLineSurveytobeabletoseethecurrent
pulledbyeachstation.
