RangerSInstallationandtroubleshooting
47
Chapter4:Troubleshootingfromthe
Controller
TestingStations
Thissectiondescribesthevariouswaysyoucantroubleshootyour
controllerandstations.
Enablingcurrentreadings
Themostimportanttoolindaytodaytroubleshootingisthebuilt‐in
currentreadings.ToenablecurrentreadingsinthedisplayoftheRanger
4000S,followthisprocedure:
1 Turnthedialto ADVANCED
Nowthedisplaylookslikethis:
