SRC RANGER 4000 S - Special Current Readings from the Station Test; Running the Water Test; Running the Test Program

RangerSInstallationandtroubleshooting
51
Note
Specialcurrentreadingsfromthestationtest
Regardlessofwhetherthestationfailsorturnsoutok,youmoveonto
testingthenextstationinlinebypushingthe ENTER button.
Runningthe"WaterTest"
The"watertest"isabuilt‐inprogramthatwillactivateall100station
identitiesinthesysteminturn.Thiswayyoucanwalkthroughthe
landscapeandensurethatallstationsareactuallypullingthevalvesopen.
Runningthetestprogram
1 TurnthedialtoMANUAL:
Reading Meaning
-1mA / -1mA
Thereisashortontheterminal(onthecontroller)
Important
Ifyouexperienceashortontheterminalandfixit,you
mustrestarttheelectricaltest,orallfollowingstationswill
appeartohaveaterminalshort.
-2mA / -2mA
Thereisasituationofoverload(morethan2Aformore
thanfiveminutes.)
-3mA / -3mA
Thereisablownfuseontheconnectboard.
Note:Thereareafewspecialreadingsthatyoushouldbe
awareof:
