RangerSInstallationandtroubleshooting
50
Ifthestationisok,thedisplaywilllooksomethinglikethis:
Inthiscasethestationispullingacurrentof238mAtokeepthevalveopen,
whichisoksincethisistypicallyinthe200‐400mArange.
Ifthestationfails,thedisplaywilllooksomethinglikethis:
Ifthestationisnotworkingcorrectlyitistypicallynotpullinganycurrent
atall‐thecurrentreadingis0mA.
Note:Thenumberbeforetheslashisthecurrentonthewire
beforetryingtoactivatethestation‐ifthisismuchmorethan
zero,therecouldbealeaksomewhere.
