RangerSInstallationandtroubleshooting
7
Thepowerdistributor
Thepowerdistributordelivers24VACtothecontrollerandtovariousAUX
connections.Italsohasapowerswitch.
24VAC in
24VAC out
24VAC out
Power switch
24VAC to controller
Controller
