7.17.2 GPIO expansion connector interface

Figure 10 shows the pinout of the CN8 GPIO connector.

Figure 10. CN8 GPIO connector

DT71714V1

CN8 pin 1

CN8 pin 2

UM2993

GPIO expansion connector

UM2993 - Rev 2

page 24/42
