9 STM32MP135F-DK I/O assignment
Table 23. STM32MP135 Discovery kit I/O assignment
Ball Pin Assignment
A2 PA9 DCMI_D0
B2 PE11 USART2_CTS
B3 PF5 LCD_INT
C2 PD3 DCMI_D5
C3 PE14 DCMI_D7
B1 PD0 DCMI_D1
D3 PH12 USART2_TX
C1 PB6 LCD_B6
D2 PD6 UART4_TX
E3 PH8 DCMI_HSYNC
D1 PB8 DCMI_D6
F4 PA12 ETH2_CRS_DV
E2 PH2 LCD_RST
F3 PD11 DCMI_D4
F2 PG9 DCMI_VSYNC
F1 PF8 PF8_WKUP
H5 PG8 ETH2_CLK
G3 PG5 ETH2_MDC
H4 PG15 ETH2_MDINT
G2 PG10 DCMI_D2
H3 PF10 EXP_GPIO7
G1 PF6 ETH2_TX_EN
J5 PF9 TIM14_CH1
H2 PE4 DCMI_D3
J3 PB2 ETH2_MDIO
J1 PH7 SPI5_SCK
K3 PH11 SPI5_NSS
J2 PD13 TIM4_CH2
L4 PI3 ETH1_MDINT
M3 PC13 PMIC_WAKEUP
N5 PI2 STM32G0_INTN
P4 PI1 LPO_32
P5 PI0 TAMP_IN8_OUT1
L3 PC15-OSC32_OUT OSC32_OUT
M2 PC14-OSC32_IN OSC32_IN
N2 PF4 ETH2_RXD0
P2 PA8 SPI5_MISO
N1 PE2 ETH2_RXD1
UM2993
STM32MP135F-DK I/O assignment
UM2993 - Rev 2
page 29/42
