ST STM32MP135F-DK User Manual

Ball Pin Assignment
P3 PF7 ETH2_TXD0
R2 PG11 ETH2_TXD1
N3 PH6 I2C5_SDA
R1 PG1 FDCAN2_TX
T2 PE6 MCO2
T3 PH0-OSC_IN HSE_IN
U2 PH1-OSC_OUT HSE_OUT
R3 PH3 SPI5_MOSI
W1 PG3 FDCAN2_RX
V3 PG2 ETH1_MDC
W2 PG12 MCP_INT
V1 PD7 MCO1
T4 PA13 PA13 (user button 2)
Y1 PA11 ETH1_CLK
AA2 PB11 ETH1_TX_EN
Y2 PF14 STLINK_SWCLK
Y3 PA0 SAI1_SDB
W4 PF13 DFSDM1_DATIN3
AA3 PA1 ETH1_RX_CLK
Y4 PA2 ETH1_MDIO
Y5 PA5 SAI1_SDA
W5 PC0 USART1_TX
AA4 PF12 USB_PWR_CC1
V6 PA7 USART1_CTS
Y6 PF11 SAI1_FSA
AA6 PA4 SAI1_SCKA
Y7 PC4 ETH1_RXD0
W6 PC3 DFSDM1_CKOUT
AA7 PC5 ETH1_RXD1
W8 PB0 USART1_RX
W9 PA3 USB_PWR_CC2
Y8 PB1 TIM3_CH4
Y9 PC1 ETH1_CRS_DV
U10 PA6 TAMP_BTN
AA9 PG13 ETH1_TXD0
W10 PE5 TIM8_CH3
Y10 PG14 ETH1_TXD1
AA10 PC2 USART1_RTS
AA13 USB_DP2 USB_DP2
Y13 USB_DM2 USB_DM2
Y12 PF15 STLINK_SWDIO
UM2993
STM32MP135F-DK I/O assignment
UM2993 - Rev 2
page 30/42
