ST STM32MP135F-DK User Manual

Ball Pin Assignment
W13 PA14 PA14 (user button 1)
AA15 PI5-BOOT1 BOOT1
Y15 PI6-BOOT2 BOOT2
Y17 PI4-BOOT0 BOOT0
AA16 USB_DM1 USB_DM1
Y16 USB_DP1 USB_DP1
AA19 PA10 STM32G0_WAKE
AA20 PI7 LCD_DISP
Y19 PH4 uSD_DETECT
W18 PH5 STLINK_SWO
A20 PC9 SDMMC1_D1
C18 PC8 SDMMC1_D0
C19 PD2 SDMMC1_CMD
A19 PC12 SDMMC1_CK
A18 PC10 SDMMC1_D2
B18 PC11 SDMMC1_D3
C17 PG6 SDMMC2_CMD
B17 PE3 SDMMC2_CK
C16 PB4 SDMMC2_D3
B16 PB14 SDMMC2_D0
B15 PB15 SDMMC2_D1
C14 PB3 SDMMC2_D2
A16 PF0 WL_HOST_WAKE
A15 PB9 I2C4_SDA
E14 PH10 BT_PCM_SDO
D14 PB13 BT_PCM_WS
E13 PB10 BT_PCM_CK
B14 PC6 LCD_HSYNC
B13 PB5 BT_PCM_SDI
C13 PC7 LCD_G6
A13 PF3 LCD_G3
C12 PH9 LCD_DE
B11 PF1 LCD_B7
A12 PH13 LCD_G2
A10 PG7 LCD_R2
B10 PG4 LCD_VSYNC
C11 PB12 LCD_R3
D11 PF2 LCD_B3
C10 PE10 BT_HOST_WAKE
A9 PE15 I2C4_SCL
B8 PH14 LCD_B4
UM2993
STM32MP135F-DK I/O assignment
UM2993 - Rev 2
page 31/42
