Figure 11 shows the pinout of the CN11 VBAT connector.

Figure 11. CN11 VBAT connector pinout

Table 20

describes the VBAT interface and pinout of connector CN11.

Table 20. CN11 VBAT connector pinout

Pin Pin name Function

1 VBAT VBAT supply.

2 GND Ground.
