1 Features
• Ultra-low-power STM32U5G9ZJT6Q microcontroller based on the Arm
®
Cortex
®
‑M33 core with Arm
®
TrustZone
®
, featuring 4 Mbytes of flash memory, 3 Mbytes of SRAM, and SMPS, in an LQFP144 package
• 5" 800 × 480 pixels TFT LCD module with 16.7M color depth, parallel RGB interface, and capacitive touch
panel
• USB Type-C
®
with USB 2.0 high-speed interface, UCPD Sink only
• Low-power system designed for VDD at 3.3 V only
• 1-Gbit Octo‑SPI flash memory
• Two user LEDs
• User and reset push-buttons
• Board connectors:
–
ST-LINK USB Type-C
®
–
User USB Type-C
®
–
Arm
®
Cortex
®
MIPI10 connector (SWD/JTAG/trace)
–
Tag‑Connect
™
10-pin footprint
–
ARDUINO
®
Uno V3 expansion
– Double-row 2.54 mm pitch expansion connector for additional peripherals prototyping
• On-board STLINK-V3EC debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the STM32CubeU5 MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
®
, MDK-ARM, and STM32CubeIDE
Note: Arm and TrustZone are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM3223
Features
UM3223 - Rev 1
page 2/37
