7.5 Display
The STM32U5G9J-DK2 Discovery kit embeds a 5-inch 800x480 TFT LCD MB1860 board, which is connected to
the RGB interface of the STM32U5G9ZJT6Q MCU through a 50-pin connector (CN3).
The MB1860 board uses the RK050HR18-CTG TFT LCD from Rocktech including a backlight and a capacitive
touch panel.
The touchscreen controller is connected to the STM32U5G9ZJT6Q MCU via the I2C2 bus, at the 0x5D address).
Table 10. Display connections
Connector MCU Connector MCU
Pin Signal Function I/O Pin Pin Signal Function I/O Pin
1 GND GND 2 GND GND
3 R0 LCD R0 PC6 98 4 G0 LCD G0 PC8 100
5 R1 LCD R1 PC7 99 6 G1 LCD G1 PC9 101
7 R2 LCD R2 PE15 61 8 G2 LCD G2 PE9 53
9 R3 LCD R3 PD8 73 10 G3 LCD G3 PE10 56
11 R4 LCD R4 PD9 74 12 G4 LCD G4 PE11 57
13 R5 LCD R5 PD10 75 14 G5 LCD G5 PE12 58
15 R6 LCD R6 PD11 76 16 G6 LCD G6 PE13 59
17 R7 LCD R7 PD12 77 18 G7 LCD G7 PE14 60
19 GND GND 20 GND GND
21 B0 LCD B0 PB9 140 22 DE LCD DE PD6 123
23 B1 LCD B1 PB2 48 24 DISP
ON/OFF
GPIO
output
PE4 3
25 B2 LCD B2 PD14 79 26 HSYNC LCD
HSYNC
PE0 141
27 B3 LCD B3 PD15 80 28 VSYNC LCD
VSYNC
PD13 78
29 B4 LCD B4 PD0 116 30 GND GND
31 B5 LCD B5 PD1 117 32 PCLK LCD CLK PD3 119
33 B6 LCD B6 PE7 51 34 GND GND
35 B7 LCD B7 PE8 52 36 TP WAKE System
NRST
NRST 28
37 GND GND 38 TPSDA I2C2 SDA PF0 10
39 TP INT GPIO
interrupt
PE5 4 40 TPSCL I2C2 SCL PF1 11
41 NC GND 42 NC -
43 BL CTRL GPIO PWM PE6 5 44 NC -
45 BL 5V 5V 46 NC -
47 BL GND GND 48 NC -
49 BL GND GND 50 VDD 3V3
49 BL GND GND 50 VDD 3V3
UM3223
Board functions
UM3223 - Rev 1
page 21/37
