STM32U5G9ZJT6Q signal Signal assignment Secondary function Usage

PG0 ADC4_IN7

ARDUINO

PG1 ADC4_IN8

ARDUINO

PG9 - Spare GPIOs -

PG10 - Spare GPIOs -

PG12 - Spare GPIOs -

PG13 I2C1_SDA

ARDUINO

SDA-D14

PG14 I2C1_SCL

ARDUINO

SCL-D15

PG15 - Spare GPIOs -

PH9 PH9-HSPI1_NCS Flash memory Chip select

PH10 HSPI1_SIO0 Flash memory Data 0

PH11 HSPI1_SIO1 Flash memory Data 1

PH12 HSPI1_SIO2 Flash memory Data 2

PH13 HSPI1_SIO3 Flash memory Data 3

PH14 HSPI1_SIO4 Flash memory Data 4

PH15 HSPI1_SIO5 Flash memory Data 5

PI0 HSPI1_SIO6 Flash memory Data 6

PI1 HSPI1_SIO7 Flash memory Data 7

PI2 HSPI1_DQS0 Flash memory Data strobe signal

PI3 HSPI1_CLK Flash memory Clock

UM3223

STM32U5G9ZJT6Q MCU I/O assignment

UM3223 - Rev 1

page 27/37
