Section 1
Pump Overview
Introduction
The IntelliPro
®
Variable Speed pump is well suited for all of your pool, spa, cleaner, waterfall and other
water applications. Using the control panel, IntelliPro
®
can use one of the four selectable preset speeds
or the pump speed can be adjusted to run at a specifi c speed. IntelliPro
®
outperforms all conventional
pumps in its class. Advanced energy conservation features ensure that your fi ltration system is operating
at peak effi ciency.
The pump can operate from 450 RPM to 3450 RPM with preset speeds of 750, 1500, 2350 and 3110
RPM. The pump can be adjusted from the control panel to run at any speed between 450 RPM to 3450
RPM for different applications. The pump control panel alarm LED and error messages warn the user
against under and over voltage, high temperature, over current and freeze protection with user defi ned
minimum and maximum speed presets.
External Control
The IntelliPro
®
Variable Speed pump can communicate with an IntelliTouch
®
, EasyTouch
®
, or SunTouch
®
control system or the IntelliComm
®
communication center via a two-wire RS-485 communication
cable. The communication cable is included with the IntelliPro
®
Variable Speed pump. EasyTouch
®
and IntelliComm
®
can remotely control the IntelliPro
®
four preset speeds. The IntelliTouch
®
system
can be confi gured to control a total of eight speeds. The pump’s address and other pump functions are
accessed from the pump’s control panel.
IntelliPro
®
Variable Speed pump
IntelliPro
®
Variable Speed Pump Installation and User’s Guide
1
