STACK Dash-2 Kart Logger 3. Operating the Dash-2 Kart Logger
Users Guide 9
Display Layer 1 - Race
• Lap Number (Lap No100)
• Laptime (0:48.76)
• Cylinder Head Temperature(CHT 250)
2
• Best Laptime (:48.22)
Press Switch 2 to see display layer 2.
Display Layer 2 - Temperatures
• Wheel Speed (Speed 101)
• Laptime (0:48.76)
• Cylinder Head Temperature (CHT 250)
2
• Exhaust Gas Temperature (EGT 675)
3
Press Switch 2 to change display to layer 3
2
The CHT position on layer 2 may be replaced with either EGT or Water, dependant upon the sensor
input type selected in the system setup.
3
The EGT position is replaced by best lap time on ST8203 systems
