Pubn No: 30000H0K
Slide Up
Switch the gas supply ON.
Light the Pilot and Test Jets.
4mm
Rotate
Check the Test Jet flame is 4mm
diameter. A 4mm circle is
engraved on the shutter plate as
a guide. Adjust if necessary by
turning the Pinch Valve.
When the countdown reaches 0
seconds …..
XX.X
o
C
0 seconds
….. a warning beep will sound.
Issue K
10 Jun 2007
18
To Next Page
