Attachment 9
Hand Held Device Troubleshooting Aid—Swing/Fold
(Sheet 1 of 1)
Terminal and Pin Description State
TB1-8 Bodyguard-T Data Output
Dark = door open
Light = door closed
Function Switch States for TB2
Hold Open OFF Auto ON Night Mode
TB2-1
TB2-3
TB2-5
TB1-5 M1 Power Close Module Control Output Dark = Power Close Acve
TB1-8 OHP1 and OHP Data Dark = Door open
TB3-4 DM1 Stall Dark = Detecng
TB3-8 and TB4-8 Safety Dark = Detecng
TB3-9 Breakout / M2 Power Close Monitoring Dark = No breakout
TB4-4 and TB4-9 Operate Sensor Input and Push Plate Input (connected internally) Dark = Detecng
TB5-3 DM1 Acvaon Dark = Detecng
TB5-7 Non-Monitored Photobeam / M1 Power Close Monitoring Dark = Detecng
TB5-10 Electric Strike Dark = On
TB6-3
Power Close Cancel and Power Assist
at Closed Mode / DM2 Stall
Dark = On
TB6-5 DM1 and OHP1 Test Dark = Normal
TB6-7 DM2 and OHP2 Test Dark = Normal
