Stanley 204143 - Attachment 10: Recommended Values for Door Configurations (Sheet 1 of 1)

iQ Control Box
46 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS
Copyright 2019, Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
10.18.2019
Attachment 10
Recommended Values for Door Configurations
(Sheet 1 of 1)
Description
Light Weight Door (150lbs)
Full Energy Low Energy
Concealed In-Swing Out-Swing Concealed In-Swing Out-Swing
Open Learn Speed 20 20 20 15 15 15
Open Learn Torque 60 50 60 35 30 35
Open Startup Torque 60 40 60 40 30 40
Open Startup Length 5 5 5 10 10 10
Open Speed 65 106 70 32 46 33
Open Torque 60 40 60 35 20 35
Open Acceleraon 10 12 10 20 12 20
Open Check Length 45 40 35 20 23 20
Open Check Speed 6 10 7 10 10 6
Open Check Torque 60 60 60 35 35 35
Open Braking 2 10 10 2 6 9
Open Stop 30 30 30 20 30 30
Open Check Recycle Speed 45 45 45 45 45 45
Attachment 10
Recommended Values for Door Configurations
Description
Heavy Weight Door (350lbs)
Full Energy Low Energy
Concealed In-Swing Out-Swing Concealed In-Swing Out-Swing
Open Learn Speed 20 20 20 15 15 15
Open Learn Torque 60 50 60 35 30 35
Open Startup Torque 60 35 60 40 25 40
Open Startup Length 5 5 5 10 10 10
Open Speed 47 108 56 32 42 20
Open Torque 60 40 60 35 20 35
Open Acceleraon 15 30 10 20 20 20
Open Check Length 45 45 36 25 25 20
Open Check Speed 10 3 12 6 10 6
Open Check Torque 60 60 60 35 35 35
Open Braking 1 4 10 2 8 2
Open Stop 40 20 30 40 30 30
Open Check Recycle Speed 55 45 45 45 45 45
Overspeed Resistance 25 25 25 25 25 25
