Attachment 11
iQ Controller Fine Tuning
(Sheet 1 of 1)
Match your actual door to one from the list of doors described in Aachment 10. Start by installing these sengs.
Use the guide below to make adjustments to these sengs.
SWING DOOR:
SYMPTOM RECOMMENDED SOLUTION
Door opens too slowly. 1. Increase Open Speed
2
.
2. Increase Open Torque
1,2
.
3. Increase Open Acceleration.
Door closes too slowly. 1. Adjust Close Speed Module or Power Close Speed Module
2
.
2. Check for mechanical binding.
Door hits the open stop too hard. 1. Increase Open Check Length unl door slows down a considerable distance
from the Open Stop.
2. Increase Open Braking unl the door slows down into Open Check.
3. Decrease Open Check Speed if door speeds up aer slowing down into
Open Check.
4. Increase Open Stop unl door no longer hits the open stop.
Door stalls while opening without
any mechanical reason.
1. Increase Open Obstruction Time and/or Open Check Obstruction Time.
2. Make small increases to Open Torque
1
and/or Open Check Torque.
Door creeps closed from full open. 1. Increase Stall Torque one count at a me unl the open posion is stable.
2. To verify new seng, door must be cycled open and return to full closed.
NOTES:
1. Open Torque is also used to set the door open force.
2. Open / Close Speeds and Forces must comply with UL and ANSI/BHMA A156.19 or 156.10 requirements.
