• SET the auxiliary cam for approximately 3° acvaon (toward breakout direcon), and ADJUST cam as necessary
to trip the corresponding micro switch prior to acvaon of the breakout switch.
• CONNECT yellow jumper wires installed on the single/dual motor harness
as follows:
a. INSTALL stripped end of rst jumper wire (from posion 3 of the 8-pin connector on operator harness) into
terminal 9 of control box connector TB3.
b. INSTALL stripped end of second jumper wire (from posion 5 of the 8-pin connector on operator harness)
into terminal 10 of control box connector TB3.
NOTE: In a swing-pair applicaon, the breakout switches of each operator need to be wired in series to en-
sure that the control box will not open the doors if either breakout status switch is acvated.
• IF applicaon is a pair of swing doors, PERFORM the following:
a. REPEAT the previous two steps for the second door operator.
b. CONNECT stripped end of one yellow jumper wire from each operator to terminals 9 and 10 of control box
connector TB3.
• Using a wire nut, CONNECT remaining wire from rst operator to remaining wire on second operator.
• VERIFY breakout status/breakout cam is properly set as follows:
a. Refer to Figure 1, and visually INSPECT cams for proper seng.
b. UNPLUG TB3 from control box.
NOTE: When checking breakout status switch connuity, the switch is rst checked with the door closed,
then again with the door in the breakout (negave 3°) posion. In a swing-pair applicaon, both doors can
be tested at the same me in the closed posion. However, the doors must be tested individually when
checking switch connuity with the doors in the breakout (negave 3°) posion.
c. ENSURE door is in the closed posion.
d. Using a mulmeter, CHECK connuity between TB3 terminals 9 and 10, and ENSURE there is connuity.
e. PUSH door in the breakout direcon, and HOLD door at approximately the negave 3° posion.
f. Using a mulmeter, CHECK connuity between TB3 terminals 9 and 10, and ENSURE there is an open circuit.
g. RELEASE door.
h. PLUG TB3 into control box.
TOP CAM = AUX SWITCH
CENTER CAM = EMERGENCY BREAKOUT SWITCH
BOTTOM CAM = CLOSE CHECK SWITCH
EMERGENCY SWITCH
N.C.: RED
N.O.: YELLOW
COM.: BLACK
OPEN CHECK SWITCH
N.O.: BROWN
COM.: ORANGE
CLOSE CHECK SWITCH
N.C.: WHITE
COM.: BLUE
TOP CAM = AUX SWITCH
CENTER CAM = EMERGENCY BREAKOUT SWITCH
BOTTOM CAM = CLOSE CHECK SWITCH
RH SHOWN LH SHOWN
Figure 1. Breakout Status/Breakout Cam Settings (Magic-Swing Operators)
