9. BILL OF MATERIAL
ID Part Description Part Number
* A, Z Collet and Collet Stop 65110-00054
* B1 Anvil, ø 26mm 65110-00057
* B2 Anvil, ø19mm 65110-00120
** C1 Nose Housing, Ø26 x 40 mm 65110-00056
** C2 Extended Nose Housing, Ø19 x 75 mm 65110-00155
** D Nose Housing Nut 65110-00083
E Gear Housing Assembly -
F Exhaust Vent -
G Handle -
H Switch -
J Manual Reverse Button -
K Worklight -
L Worklight switch -
M Battery pack See below
** N Stroke Adjustment Pin 65110-00243
P Pulling Head Adapter -
Q Front Clutch -
R Mast Housing TP113-610
S Ball Screw Assembly -
** T O-Ring TP124-505
U Front Clutch Spring -
V Stopper -
** W Spindle Clutch and Stop 65120-00015
** X Spindle Clutch Spring TP114-666
** Y Washer 65110-00242
** Z Collet Stop 65110-00244
** AA Extension 65120-00020
BB 2.0mm Hex Key 65130-00003
EE Charger See Below
** FF Wave Spring Washer 65130-00004
** GG Thrust Race TP124-558
** HH Thrust Needle Bearing TP124-557
** JJ Spindle TP113-605
** KK Parallel Key TP114-627
** N, P, Q, U, S, V Pulling Head Sub-assembly 65120-00011
Housing Screws 330019-52
Handle Screws 682211-00
* Consumable
** Recommended Spare
COUNTRY MODEL NUMBER BATTERY PACK CHARGER
INSTRUCTION
MANUAL
NA (North America) PB2500N-NA2042 DCB204-NA DCB115-NA 65104-00001
QW (EU Standard) PB2500N-QW1842
DCB182-XJ
(02731)
DCB115-QW
(02732)
65104-00005 (EU)
65104-00006 (East EU)
GB (Great Britain) PB2500N-GB1842
DCB182-XJ
(02731)
DCB115-GB
(02733)
65104-00005 (EU)
65104-00006 (East EU)
