Standard Escutcheon Assemblies
2–4 Stanley OMNILOCK Illustrated Parts Catalog
24 1 B82229 B82229 B82230 Keypad bezel
not shown
1 — B82243 B82243 IR window
25 1 3064554 — — Antenna assembly
26 1 A82291 A82291 A82291 Reader cover gasket
27 1 B82221 B82221 B82221 Front cover
f
a. For the part number for extreme weatherized battery covers, see Extreme weatherized
escutcheon components on page 2–18.
b. The 500 Series keypad reader escutcheon assembly uses two A82245 screws,
cylindrical applications use seven A82245 screws.
c. The cylindrical mounting plate uses four B82272 screws.
d. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 2–17. For best performance, use Duracell or Energizer batteries.
e. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 2–17. For part numbers for extreme weatherized circuit boards,
see Extreme weatherized escutcheon components on page 2–18.
f. Specify finish (gray, black, or satin chrome).
Item Qty.
WAMS
Part No.
2000 Series
Part No.
500 Series
Part No. Description
