Stanley OmniLock User Manual

Exit Device Trim Components
Stanley OMNILOCK Illustrated Parts Catalog 5–3
Keypad reader
escutcheon
assembly parts list
Refer to Figure 5.1 and the table below to find the part you need.
Item Qty.
WAMS
Part No.
2000 Series
Part No.
500 Series
Part No. Description
1 1 B82267 B82267 B82267 Housing gasket
2 1 B82735 B82735 B82735 Exit device bearing
3 1 A82719 A82719 A82719 Battery cover screw
(#4–40 × 1″ Phillips flat head)
4 3 A82724 A82724 A82724 Mounting plate screw
(#8–32 × 5/8″ Phillips flat head)
5 1 A82723 A82723 A82723 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
6 1 B82736 B82736 B82736 Battery cover
7 1 B82734 B82734 B82734 Exit device mounting plate
8 2 A82720 A82720 A82720 Battery cover pad
9 3 A82272 A82272 A82272 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
10 1 B82745 B82745 B82745 Quick adapter assembly
11 1 B82738 B82738 B82738 Quick adapter rose
12 1 A82265 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
a
a. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 5–12. For best performance, use Duracell or Energizer batteries.
13 6
b
b. The 500 Series keypad reader escutcheon assembly uses two A82245 screws.
A82245 A82245 A82245 Escutcheon assembly screw
(#4–40 × 1/4″ Phillips pan head)
not shown
4 — — A82288 Cover mounting screw
(Phillips pan head)
14 1 3064470 3061490 3108402 Circuit board
c
c. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 5–12.
15 1 A82249 A82249 A82249 Reader cable assembly
16 1 B82215 B82215 B82215 Reader housing
d
d. Specify finish (gray, black, or satin chrome).
17 1 A82202 A82202 A82202 Left bezel spring
18 1 A82201 A82201 A82201 Right bezel spring
19 1 B82546 B82546 B82547 Keypad assembly
20 4 A82206 A82206 A82206 Keyboard mounting screw
(#4–40 × 1/4″ Phillips flat head)
21 1 B82242 B82242 B82242 Set of keypad keys
d
22 1 B82229 B82229 B82230 Keypad bezel
not shown
1 — B82243 B82243 IR window
23 1 3064554 — — Antenna assembly
24 1 A82291 A82291 A82291 Reader cover gasket
25 1 B82221 B82221 B82221 Front cover
d
