Exit Device Trim Components
5–16 Stanley OMNILOCK Illustrated Parts Catalog
OTHER COMPONENTS
Other components
list
Refer to Figure 5.10 and the table below to find the part you need.
Figure 5.10 Other components for exit device hardware trim
12 3
Item Qty. Part No. Description
1 1 B56165 7KC throw member
2 1 A82704 6-pin metal insert
3 1 A82727 D80 driver
not shown
1 C83001 I/C lever spindle
