Cylindrical Components
4–6 Stanley OMNILOCK Illustrated Parts Catalog
STRIKE BOXES AND STRIKE PLATES
Strike boxes and
strike plates
parts list
Refer to Figure 4.5 and the table below to find the part you need.
Figure 4.5 Cylindrical strike boxes and strike plates
ANSI strike package Standard strike package
Finish and Part Number
Item 612
a
a. Satin bronze, clear coated finish.
613
b
b. Oxidized satin bronze, oil rubbed finish.
626
c
c. Satin chromium plated finish.
690
d
d. Dark bronze, powder coated finish.
ANSI strike and screws 1228455 1228460 1228434 1781319
ANSI plastic strike box B34380
e
e. This item is not finish specific.
ANSI magnetized strike box B61224
e
Standard strike and screws 1228366 1228371 1228324 1905100
Standard steel strike box B25640
e
