Stanley OmniLock User Manual

Standard Escutcheon Assemblies
Stanley OMNILOCK Illustrated Parts Catalog 2–3
Keypad reader
escutcheon
assembly parts list
Refer to Figure 2.1 and the table below to find the part you need.
Item Qty.
WAMS
Part No.
2000 Series
Part No.
500 Series
Part No. Description
1 2 A82573 A82573 A82573 Standard door mounting screw
(1–1/4″ TORX
®
T15 button head)
(mortise locks only)
not shown
2 A82574 A82574 A82574 Thick door mounting screw
(1–1/2″ TORX
®
T15 button head)
(mortise locks only)
2 2 A82212 A82212 A82212 Flat nylon washer
(mortise locks only)
3 1 B82267 B82267 B82267 Housing gasket
4 1 A82271 A82271 A82271 Battery cover
a
56
b
A82245 A82245 A82245 Escutcheon assembly screw
(#4–40 × 1/4″ Phillips pan head)
not shown
4 — — A82288 Cover mounting screw
(Phillips pan head)
6 1 B82296 B82296 B82296 Mortise mounting plate
not shown
1 B82277 B82277 B82277 Cylindrical mounting plate
7 2 A82300 A82300 A82300 Mounting plate standoff
(mortise locks only)
82
c
B82272 B82272 B82272 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
9 1 A82299 A82299 A82299 Grounding spring
10 1 A82309 A82309 A82309 Grounding spring screw
(#6–32 × 1/4″ Phillips pan head)
11 1 A82265 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
d
12 1 3064470 3061490 3108402 Circuit board
e
13 1 A82086 A82086 A82086 Battery cover standoff
14 1 A82786 A82786 A82786 Cable clamp mounting screw
(mortise locks only)
15 1 A82554 A82554 A82554 Cable clamp
(mortise locks only)
16 1 B82852 B82852 B82852 Motor wire harness
17 1 A82249 A82249 A82249 Reader cable assembly
not shown
1 A82262 A82262 A82262 Cylindrical rose gasket
18 1 B82215 B82215 B82215 Reader housing
f
19 1 A82202 A82202 A82202 Left bezel spring
20 1 A82201 A82201 A82201 Right bezel spring
21 1 B82546 B82546 B82547 Keypad assembly
22 4 A82206 A82206 A82206 Keyboard mounting screw
(#4–40 × 1/4″ Phillips flat head)
23 1 B82242 B82242 B82242 Keypad key set
f
