Cylindrical Components
Stanley OMNILOCK Illustrated Parts Catalog 4–5
LATCHES
Latches list Refer to Figure 4.4 and the table below to find the part you need.
Figure 4.4 Cylindrical latches
2 3/4″ Latch 2 3/4″ Latch with
3/4″ throw
3 3/4″ Latch 5″ Latch
Finish and Part Number
Item 612
a
a. Satin bronze, clear coated finish.
613
b
b. Oxidized satin bronze, oil rubbed finish.
626
c
c. Satin chromium plated finish.
690
d
d. Dark bronze, powder coated finish.
2 3/4″ Latch 1414488 1414520 1414645 1781235
2 3/4″ Latch with 3/4″ throw 1905027 1894471 1243824 1894471
3 3/4″ Latch 1415209 1415240 1415366 1792425
5″ Latch 1415607 1415649 1415738 1763546
