Standard Escutcheon Assemblies
Stanley OMNILOCK Illustrated Parts Catalog 2–13
28 1 B82229 B82229 Keypad bezel
not shown
1 — B82243 IR window
29 1 3064554 — Antenna assembly
30 1 A82208 A82208 Magnetic head pin
31 1 B82222 B82222 Front cover
f
a. For the part number for extreme weatherized battery covers, see Extreme weatherized
escutcheon components on page 2–18.
b. Cylindrical applications use seven A82245 screws.
c. The cylindrical mounting plate uses four B82272 screws.
d. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 2–17. For best performance, use Duracell or Energizer batteries.
e. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 2–17. For part numbers for extreme weatherized circuit boards,
see Extreme weatherized escutcheon components on page 2–18.
f. Specify finish (gray, black, or satin chrome).
