Standard Escutcheon Assemblies
2–16 Stanley OMNILOCK Illustrated Parts Catalog
28 1 B82229 B82229 Keypad bezel
not shown
1 — B82243 IR window
29 1 3064554 — Antenna assembly
30 1 A82291 A82291 Cover gasket
31 1 3062337 2062337 Clear tubing
32 1 B82293 B82293 Proximity reader antenna
33 1 B82223 B82223 Front cover
f
a. For the part number for extreme weatherized battery covers, see Extreme weatherized
escutcheon components on page 2–18.
b. Cylindrical applications use seven A82245 screws.
c. The cylindrical mounting plate uses four B82272 screws.
d. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 2–17. For best performance, use Duracell or Energizer batteries.
e. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 2–17. For part numbers for extreme weatherized circuit boards,
see Extreme weatherized escutcheon components on page 2–18.
f. Specify finish (gray, black, or satin chrome).
Item Qty.
WAMS
Part No.
2000 Series
Part No. Description

Stanley OmniLock Specifications

General

Brand	Stanley
Model	OmniLock
Category	Locks
Language	English
