Standard Escutcheon Assemblies
Stanley OMNILOCK Illustrated Parts Catalog 2–19
Extreme
weatherized
escutcheon
parts list
The extreme weatherized option is available for OMNILOCK 500 Series
and 2000 Series Locks. Extreme weatherized escutcheon assemblies
include all of the components listed for the corresponding standard
escutcheon assembly except for the battery cover and circuit board.
They also include the additional components listed below. Refer to
Figure 2.7 and the table below to find the part you need.
Item Qty.
2000 Series
Part No.
500 Series
Part No. Description
1 1 B82856 B82856 Weatherized reader battery cover
2 1 B82857 B82857 Wire assembly
3 1 3092430 3092430 Weatherized circuit board
a
a. The weatherized circuit board is not sold individually. It is provided with weatherized
housing assemblies.
4 1 B82747 B82747 Interior electronics housing
5 2 A82575 A82575 Screw (#8–32 × 3/4″ TORX
®
T15 button head)
6 1 A82555 A82555 Nut
7 1 A83017 A83017 Wire assembly
8 1 A82269 A82269 Foam pad
9 1 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
10 4 A82245 A82245 Screw (#4–40 × 1/4″ Phillips pan head)
11 1 3108334 3107901 Weatherized circuit board
12 1 O10665-2 O10665-2 Nut
13 1 O11706-1 O11706-1 Quick disk terminal
14 4 O10421-1 O10421-1 Housing bracket screw (#8 × 1/2″ )
15 1 B82748 B82748 Housing bracket
16 1 O10951 O10951 Housing bracket gasket
