Stanley OmniLock User Manual

Exit Device Trim Components
Stanley OMNILOCK Illustrated Parts Catalog 5–7
Proximity reader
escutcheon
assembly parts list
Refer to Figure 5.3 and the table below to find the part you need.
Item Qty.
WAMS
Part No.
2000 Series
Part No. Description
1 1 B82267 B82267 Housing gasket
2 1 B82735 B82735 Exit device bearing
3 2 A82720 A82720 Battery cover pad
4 1 B82736 B82736 Battery cover
5 1 A82719 A82719 Battery cover screw
(#4–40 × 1″ Phillips flat head)
6 6 A82245 A82245 Escutcheon assembly screw
(#4–40 × 1/4″ Phillips pan head)
7 1 B82734 B82734 Exit device mounting plate
8 3 A82724 A82724 Mounting plate screw
(#8–32 × 5/8″ Phillips flat head)
9 1 A82723 A82723 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
10 3 A82272 A82272 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
11 1 B82745 B82745 Quick adapter assembly
12 1 B82738 B82738 Quick adapter rose
13 1 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
a
a. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 5–12. For best performance, use Duracell or Energizer batteries.
14 1 3064470 3061490 Circuit board
b
b. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 5–12.
15 1 A82249 A82249 Reader cable assembly
16 1 3062138 3062138 Proximity reader cable assembly
17 4 A82224 A82224 Proximity reader circuit board screw
(#2-56 Phillips pan head)
18 1 3062096 3062096 Proximity reader circuit board
19 4 A82225 A82225 Spacer
20 1 B82214 B82214 Reader housing
c
c. Specify finish (gray, black, or satin chrome).
21 1 A82202 A82202 Left bezel spring
22 1 A82201 A82201 Right bezel spring
23 1 B82546 B82546 Keypad assembly
24 4 A82206 A82206 Keyboard mounting screw
(#4–40 × 1/4″ Phillips flat head)
25 1 B82211 B82211 Bezel
not shown
1 — B82243 IR window
26 1 3064554 — Antenna assembly
27 1 A82291 A82291 Reader cover gasket
28 1 3062337 2062337 Clear tubing
29 1 B82293 B82293 Proximity reader antenna
30 1 B82223 B82223 Front cover
c
