Exit Device Trim Components
Stanley OMNILOCK Illustrated Parts Catalog 5–9
Dual validation
reader (keypad and
magnetic stripe)
escutcheon
assembly parts list
Refer to Figure 5.4 and the table below to find the part you need.
Item Qty.
WAMS
Part No.
2000 Series
Part No. Description
1 1 B82267 B82267 Housing gasket
2 1 B82735 B82735 Exit device bearing
3 1 A82719 A82719 Battery cover screw
(#4–40 × 1″ Phillips flat head)
4 3 A82724 A82724 Mounting plate screw
(#8–32 × 5/8″ Phillips flat head)
5 1 A82723 A82723 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
6 1 B82736 B82736 Battery cover
7 1 B82734 B82734 Exit device mounting plate
8 2 A82720 A82720 Battery cover pad
9 3 A82272 A82272 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
10 1 B82745 B82745 Quick adapter assembly
11 1 B82738 B82738 Quick adapter rose
12 1 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
a
a. For the part numbers for weatherized batteries, see Weatherized escutcheon
components on page 5–12. For best performance, use Duracell or Energizer batteries.
13 6 A82245 A82245 Escutcheon assembly screw
(#4–40 × 1/4″ Phillips pan head)
14 1 3064470 3061490 Circuit board
b
b. For the part numbers for weatherized circuit boards, see Weatherized escutcheon
components on page 5–12.
15 1 A82249 A82249 Reader cable assembly
16 1 A82210 A82210 Magnetic head spring
17 1 A82205 A82205 Magnetic head retaining ring
18 1 B82228 B82228 Magnetic head assembly
19 1 A82207 A82207 Magnetic head pivot pin
20 1 B82215 B82215 Reader housing
c
c. Specify finish (gray, black, or satin chrome).
21 1 A82202 A82202 Left bezel spring
22 1 A82201 A82201 Right bezel spring
23 1 B82546 B82546 Keypad assembly
24 4 A82206 A82206 Keyboard mounting screw
(#4–40 × 1/4″ Phillips flat head)
25 1 B82242 B82242 Set of keypad keys
c
26 1 B82229 B82229 Keypad bezel
27 1 3064554 — Antenna assembly
not shown
1 — B82243 IR window
28 1 A82208 A82208 Magnetic head pin
29 1 B82222 B82222 Front cover
c
