Wall Mount System Components
Stanley OMNILOCK Illustrated Parts Catalog 6–7
Dual validation
reader (keypad and
proximity)
escutcheon
assembly parts list
Refer to Figure 6.3 and the table below to find the part you need.
Item Qty.
WAMS
Part No.
2000 Series
Part No. Description
1 1 B82267 B82267 Housing gasket
2 1 A82271 A82271 Battery cover
a
a. For the part number for extreme weatherized battery covers, see Extreme weatherized
escutcheon components on page 6–9.
3 7 A82245 A82245 Escutcheon assembly screw
(#4–40 × 1/4″ Phillips pan head)
4 1 B82548 B82548 Wall mounting plate
5 4 B82272 B82272 Mounting plate screw
(#8–32 × 3/8″ Phillips flat head)
6 2 A82557 A82557 Hollow wall anchor
7 2 A82332 A82332 self tapping screw or
not shown
2 A82549 A82549 Masonry anchor screw
8 1 A82556 A82556 Wire assembly
9 1 A82553 A82553 Cable clamp
10 1 B82551 B82551 Wire relay assembly
11 1 A82555 A82555 Nut
12 1 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
b
b. For the part numbers for weatherized batteries, see Weatherized components on
page 6–8. For best performance, use Duracell or Energizer batteries.
13 1 A82086 A82086 Battery cover standoff
14 1 3064470 3061490 Circuit board
c
c. For the part numbers for weatherized circuit boards, see Weatherized components on
page 6–8. For part numbers for extreme weatherized circuit boards, see Extreme
weatherized escutcheon components on page 6–9.
15 1 A82249 A82249 Reader cable assembly
16 1 3062138 3062138 Proximity reader cable assembly
17 4 A82224 A82224 Proximity reader circuit board screw
(#2-56 Phillips pan head)
18 1 3062096 3062096 Proximity reader circuit board
19 4 A82225 A82225 Spacer
20 1 B82203 B82203 Proximity reader housing
d
d. Specify finish (gray, black, or satin chrome).
21 1 A82202 A82202 Left bezel spring
22 1 A82201 A82201 Right bezel spring
23 1 B82546 B82546 Keypad assembly
24 4 A82206 A82206 Keyboard mounting screw
(#4–40 × 1/4″ Phillips flat head)
25 1 B82242 B82242 Set of keypad keys
d
26 1 B82229 B82229 Keypad bezel
27 1 3064554 — Antenna assembly
not shown
1 — B82243 IR window
28 1 A82291 A82291 Cover gasket
29 1 3062337 2062337 Clear tubing
30 1 B82293 B82293 Proximity reader antenna
31 1 B82223 B82223 Front cover
d
