Wall Mount System Components
6–10 Stanley OMNILOCK Illustrated Parts Catalog
Extreme
weatherized
escutcheon
parts list
The extreme weatherized option is available for OMNILOCK 500 Series
and 2000 Series Locks. Extreme weatherized escutcheon assemblies
include all of the components listed for the corresponding standard
escutcheon assembly except for the battery cover and circuit board.
They also include the additional components listed below. Refer to
Figure 6.5 and the table below to find the part you need
Item Qty.
2000 Series
Part No.
500 Series
Part No. Description
1 1 3108334 3107901 Weatherized circuit board
a
a. The weatherized circuit board is not sold individually. It is provided with weatherized
housing assemblies.
2 1 B82856 B82856 Weatherized reader battery cover
3 4 A82245 A82245 Screw (#4–40 × 1/4″ Phillips pan head)
4 1 B82849 B82849 Housing cover
5 1 A82269 A82269 Foam pad
6 1 A82265 A82265 Set of 4 batteries (AA alkaline, 1.5V)
7 1 3092430 3092430 Interconnecting circuit board
8 1 B82848 B82848 Housing
9 1 A82487 A83017 Wire assembly
10 1 B82551 B82551 Wire relay assembly
11 2 A82555 A82555 Nut
12 1 A82553 A82553 Nylon cable clamp
not shown
6 A82557 A82557 Hollow wall anchor
not shown
6 A82332 A82332 Self tapping screw or
not shown
6 A82549 A82549 Masonry anchor screw
