Assignable Input and Output Functions
QB Expert Alpha Controller
128
Outputs Description
Configuration Options
CYCLE OK Fastening cycle was OK Contact Type, Type, Time, Spindle
CYCLE STOPPED Shut off code is STOP Contact Type, Time, Spindle
DISASSEMBLY DETECTED A tightened fastener removed has been loosened Contact Type, Type, Time, Spindle
*FAULT CODE Fault code value Data Type, Spindle
FAULTED A fault condition is active Contact Type, Type, Time, Spindle
IN CYCLE The tool is in cycle Contact Type, Type, Time, Spindle
IN REVERSE The tool mode is Reverse Contact Type, Type, Time, Spindle
JOB COMPLETE Job complete (all bolts in job are OK) Contact Type, Type, Time, Job, Spindle
JOB SELECTED Indicates a specific job is selected Contact Type, Type, Time, Job, Spindle
JOB SELECTED (BIT) A bit to indicate the selected job in a series of bits Contact Type, Bit, Mode, Spindle
MULTI-FUNCTION
BUTTON
Shows the state of the multifunction button Contact Type, Type, Time, Spindle
NOT USED Output is not in use None
*PARAMETER Parameter number Data Type, Param, Step, Spindle
*PART ID Active PART ID Data Type, Spindle
PM The tool requires service Contact Type, Type, Time, Spindle
READY The tool is ready to run Contact Type, Type, Time, Spindle
*RUNDOWN BOLT Accumulated Bolt Count of last fastening cycle Data Type, Spindle
*RUNDOWN DAY Day of last fastening cycle Data Type, Spindle
*RUNDOWN HOUR Hour of last fastening cycle Data Type, Spindle
*RUNDOWN JOB Job of last fastening cycle Data Type, Spindle
*RUNDOWN MINUTE Minute of last fastening cycle Data Type, Spindle
*RUNDOWN MONTH Month of last fastening cycle Data Type, Spindle
*RUNDOWN PART ID Last fastening cycle PART ID Data Type, Spindle
*RUNDOWN SECOND Second of last fastening cycle Data Type, Spindle
*RUNDOWN STATUS Overall status of last fastening cycle Data Type, OK, NOK, Spindle
*RUNDOWN TASK Task of last fastening cycle Data Type, Spindle
*RUNDOWN UNITS Torque Units of last fastening cycle Data Type, Spindle
*RUNDOWN YEAR Year of last fastening cycle Data Type, Spindle
SNUG ACHIEVED Is set when Snug torque exceeded Contact Type, Type, Time, Spindle
START TRIGGER Shows the state of the tool trigger Contact Type, Type, Time, Spindle
STEP BIT Indicates last step of fastening cycle in a series of bits Contact Type, Bit, Mode, Spindle
STOPPED A STOP input is asserted Contact Type, Type, Time, Spindle
TASK COMPLETE Task complete (all bolts in task are OK) Contact Type, Type, Time, Task, Spindle
TASK SELECTED Indicates a specific task is selected Contact Type, Type, Time, Task, Spindle
