Stanley QB Expert User Manual

Assignable Input and Output Functions
QB Expert Alpha Controller
132
Inputs
Description
SELECT JOB
(BIT)
When asserted or removed on any input type, the controller selects a job. This is one bit, in a series of bits, to create
a binary number.
See SELECT TASK (BIT) function description for explanation of this bit (note that this references Jobs not Tasks).
Size: 1 bit, except on fieldbus where it can be any size to fit the need.
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Bit: Type the number of this bit, in the binary number scheme, to select jobs.
Mode: All JOB SELECT BITs must be the same mode, modes cannot be mixed.
Binary – Creates a decimal number equivalent to the weighted value of this binary bit(s).
Binary + 1 – Creates a number equivalent to the weighted value of this binary bit(s) and adds the value of one
(1) to that number.
Spindle: Spindle: Type the spindle number in which the job is to be selected.
SELECT TASK
When asserted, on any input type, the controller makes this input’s Task the active Task.
When removed either nothing happens or if “Disable when open” is selected as yes, then the tool becomes
disabled.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Task: Type the Task number to select when this input is asserted.
Disable when open:
Yes – Disables the tool when this input is removed.
No – Does not disable the tool upon input removal.
Spindle: Spindle: Type the spindle number in which the task is to be selected.
