Controller Connections
Instruction Manual
131
Inputs
Description
RESET JOB
When asserted, on any input, the controller resets the accumulated bolt count to zero for the active job and
acts as a part entry to re-enable the tool if disabled. The tool could be disabled due to “Error Proofing” and the
accumulated bolt count equal to target bolt count.
When removed nothing happens.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Spindle: Type the spindle number in which the job is to be reset.
RESET RESULT
STATUS
When asserted on any input bus, the controller resets to 0 (zero) any fastening cycle results status output bit on the
same bus. Meaning, if asserted on DeviceNet, only the DeviceNet output status bits are reset. Output status bits on
other buses will remain in their original state.
The list of status bits that will reset are:
CYCLE OK CYCLE NOK
TORQUE OK TORQUE HIGH
TORQUE LOW ANGLE OK
ANGLE HIGH ANGLE LOW
CYCLE ABORTED CYCLE STOP
CURRENT OK CURRENT HIGH
CURRENT LOW
When removed nothing happens.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Spindle: Type the spindle number in which the result status is to be reset.
REVERSE
When asserted on any input bus, the tool is placed in Reverse (disassembly) mode. This does NOT run the tool in
Reverse mode, it changes the tool mode from Forward to Reverse. If one input is required to do both functions, see
REVERSE START.
When removed, from any input type, the controller places the tool into Forward (assembly) mode.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Spindle: Type the spindle number for the tool to be put into reverse.
SELECT JOB
When asserted, on any input type, the controller makes this input’s Job the active Job.
When removed either nothing happens or if “Disable when open” is set to yes, then the tool becomes disabled.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Job: Type the job number to select when this input is asserted.
Disable when open:
Yes – Disables the tool when this input is removed.
No – Does not disable the tool upon input removal.
Spindle: Spindle: Type the spindle number in which the job is to be selected.
