Assignable Input and Output Functions
QB Expert Alpha Controller
136
Outputs
Description
*ANGLE
This output is the peak achieved angle value during the fastening cycle from the Audit step. It asserts when
the fastening cycle is complete (before the IN CYCLE bit resets). The value resets to zero (0) when the tool is
commanded to run again.
Size: Can be any size from 0 to 32 bytes depending on Data Type
Data Type: Float, Int8, Int16, Int32, Fixed Point, String
Step: Audit, Audit-1, Audit-2
Spindle: Type the spindle number from which the angle value comes.
ANGLE HIGH
Asserts at the end of a fastening cycle when the achieved angle value is above the High Angle limit for the Audit
step. Resets when the tool is commanded to start again. Can also be reset with the RESET RESULTS STATUS
input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Step: Audit, Audit-1, Audut-2
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the angle status comes.
ANGLE LOW
Asserts at the end of a fastening cycle when the achieved angle value is below the Low Angle limits for the
Audit step. Resets when the tool is commanded to start again. Can also be reset with the RESET RESULTS
STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Step: Audit, Audit-1, Audut-2
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the angle status comes.
ANGLE OK
Asserts at the end of a fastening cycle when the achieved angle value is within limits for the Audit step. Resets
when the tool is commanded to start again. Can also be reset with the RESET RESULTS STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Step: Audit, Audit-1, Audut-2
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the angle status comes.
