Stanley QB Expert User Manual

Assignable Input and Output Functions
QB Expert Alpha Controller
144
Outputs
Description
SNUG ACHIEVED
Asserts at the end of a fastening cycle if the achieved torque value exceeds the Snug Torque value during the
fastening cycle. Resets when the tool is commanded to run again. Can also be reset with the RESET RESULTS
STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Step: Audit, Audit-1, Audut-2
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the signal comes.
START TRIGGER
Asserts when the tool’s trigger is pressed. Resets when the tool trigger is released.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the signal comes.
STEP (BIT)
Asserts at the end of the fastening cycle to indicate the last step ran. This is one bit, in a series of bits, to create
a binary number.
Size: 1 bit, except on fieldbus where it can be any size to fit the need.
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Bit: Type the number this bit will be in the binary number scheme for steps.
Mode: All STEP BITs must be the same mode, no mixing of modes allowed.
Binary – Creates a decimal number equivalent to the weighted value of this binary bit(s).
Binary + 1 – Creates a number equivalent to the weighted value of this binary bit(s) and add the value
of one (1) to that number.
Spindle: Type the spindle number from which the signal comes.
STOPPED
Asserts when the STOP input is received, or anytime the tool is stopped. Resets when the STOP input or the Stop
Tool Operation is reset. The icon is on when this output is on.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the signal comes.
TASK COMPLETE
Asserts when a task is complete (all bolts assigned to task are OK). Resets when a task is selected.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Task: Type the task number that, when completed, asserts this output.
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the signal comes.
