Programming
Instruction Manual
33
Low Angle
The minimum allowed angle during this step. The Wizard chooses the value of zero
degrees as default.
See parameter definitions from the other selected strategies.
The Audit step is now defined. The Wizard uses the median value, between the High and Low parameters, as the
Target. It also calculates and programs other parameters automatically, including: Snug Torque, Threshold Torque,
Statistical Torque and High Angle Bailout. Change these values after saving Wizard programming if desired.
Next, select the controls (Smart Steps) specific to your application.
Multiple step strategies are ways of using more than one step to meet the requirements of a difficult joint. The
following features are available through multiple strategies programmed via the Wizard.
Use the Toggle button to select or deselect the controls specific to your application. Press the NEXT interactive
menu button to view the option screens for each specific control chosen. The Wizard makes assumptions,
calculates and presents specific values. Modify these values if necessary.
Not Selected
Selected
AC/TC Selected
To Next Page
