TECHNICAL DATA
DIMENSIONS - STARCUS F35
Model STARCUS F35
Max. torque 35 Nm
Rated torque 25 Nm
Shaft rotational speed 24-32 rpm
Shaft diameter
Ø 25.4 mm
Static holding torque 400 Nm
Door area ≤18 m
2
Input power 220-240 V
Motor power 350W
Control unit power supply 24V DC
Thermal protection limit 105°C
Max. cycles per hour (eciency) 20
IP protection rating IP 54
Max door height/ max. number of shaft revolutions 15 rpm (5 m)
Operating temperature -20/+40 (+60) °C
