STARCUS F35 - Function Parameter Settings; Travel Limit Settings

55
O. —
O. —
Press and hold SET button for about 6 seconds
to enter travel limit setting until “0.-” appears on
the display then release the button.
Press SET to enter travel limit setting menu,
the digital displays now you can set the
OPEN Position Limit.
Click the button UP/DOWN to adjust the open
limit position of the door. Click the SET button to
conrm the open limit position.
Digital now displays automatically
now you can set the CLOSE position limit.
Click the button UP/DOWN, to adjust the close
position limit. Click the SET button to conrm.
Then the door drive would automatically open
and close the door and save the setting.
E O
PS: If there is a faulty E O , please check if
the encoder cable is connected properly. If the
connection is normal, please reset the travel
limit. When you reset the travel limit, short click
the UP /DOWN button and then reset the travel
limit.
SETTINGS OF FUNCTION PARAMETERS IN MENU
