138
Global Effects
Effects Reference
Graphic EQ
This equalizer has ten frequency bands that can be cut or boosted by up to 12dB with
a fader. In addition, there are general controls for setting the overall range and output
of the equalizer.
Output
This controls the overall output level of the equalizer.
Mode
The Mode option allows you to add color or character to the equalized output. The
following options are available:
Range
This adjusts the maximum cut or boost in dB for all frequency bands together.
Invert
Activate this to invert the EQ curve. The frequency bands that are boosted are cut,
and vice versa.
Flatten
Click this button to reset all frequency bands to 0 dB.
Mode Description
True Response Serial filters with accurate frequency response.
Classic Parallel filters where the resonance depends on the amount of gain.
Constant Q Parallel filters where the resonance is raised when boosting the
gain.
