37
Editing
Editing Layers
The following parameters are available:
Ring Modulation (RING)
Ring modulation produces the sums and the differences between the frequencies of
two signals.
• To activate the ring modulation, click the On/Off button.
Ö Make sure to switch off ring modulation when the function is not needed. When kept
on, it uses CPU cycles even if the Ring Modulation is not heard, such as in a situation
where the level is set to 0
%.
The following parameters are available:
Noise
Noise is used for non-pitched sounds. In addition to standard white and pink noise,
there are also band pass filtered (BPF) versions of white and pink noises.
• To activate the noise generator, click its On/Off button.
Ö Please make sure to switch off the noise generator when the function is not needed.
When kept on, it uses CPU cycles even if the noise is not heard, such as in a situation
where the level is set to 0
%.
The following parameters are available:
Ö The Sub Level, Ring Modulation Level and Noise Level can be modulated separately
in the modulation matrix (see
“The Modulation Matrix Subpage” on page 57).
Parameter Description
Sub Oscillator Type Here you can select the wave shape of the sub oscillator. You can
choose between Sine, Triangle, Saw, Square, Pulse Wide and
Pulse Narrow.
Sub Oscillator Level This adjusts the output level of the sub oscillator.
Parameter Description
Ring Modulation
Source 1/2
This allows you to select the sources that will be ring modulated. You
can select OSC1 or Sub as Source 1 and OSC2 or OSC3 as
Source 2. Make sure the corresponding oscillators are activated
when you select them. Otherwise, you will not hear any sound.
Ring Modulation
Level
This adjusts the output level of the Ring Modulation.
Parameter Description
Noise Type Here you can select the sound color of the noise. You can either
select White, Pink, White BPF or Pink BPF.
Noise Level This adjusts the output level of the noise generator.
