Software
UR44 Operation Manual 12
6 Effect On/Off
Turns the Effect on (lit) and off (dark).
7 Effect Edit
Opens (lit) and closes (dark) the selected effect setup
window.
8 Effect Type
Indicates the effect type.
The maximum number of Channel Strip and Guitar
Amp Classics iterations which can be used
simultaneously has restrictions. Refer to the
“Limitations on the use of effects” (page 34).
9 REV-X Send
Adjusts the signal level which is sent to REV-X.
Range: -∞ dB – +6.00 dB
) Pan
Adjusts the pan.
Range: L16 – C – R16
! Mute
Turns the mute on (lit) and off (dark).
@ Solo
Turns the solo on (lit) and off (dark).
# +48V
Indicates the on/off status of the phantom power
function of the device.
$ Fader
Adjusts the signal level.
Range: -∞ dB – +6.00 dB
DAW Area
This is the area for configuring the DAW channel
settings.
1 Level Meter
Indicates the signal level.
2 Pan
Adjusts the pan.
Range: L16 – C – R16
3 Mute
Turns the mute on (lit) and off (dark).
4 Solo
Turns the solo on (lit) and off (dark).
5 Fader
Adjusts the signal level.
Range: -∞ dB – +6.00 dB
1
2
3
4
5
